FF100R12RT4 1200V/100A 3-in-1 IGBT Module Integrated Brake Chopper Low VCE(sat) High Speed Switching Low Loss Built-in NTC Isolated Baseplate for Industrial Drives & UPS Systems
Features
Applications
-
High Power Converters
-
Motor Drives
-
UPS Systems
Description
The FF100R12RT4 is a highly integrated IGBT power module that combines a complete three-phase inverter and a braking chopper circuit in a single compact package. Rated for 1200V and 100A, it offers a space-efficient and reliable solution for motor control and power conversion. The module is designed for high efficiency and performance, featuring low collector-emitter saturation voltage (VCE(sat)) and low switching losses.
This integration simplifies system design, reduces external component count, and enhances overall reliability. Key features include a built-in NTC thermistor for real-time temperature monitoring and a fully isolated baseplate for safe and straightforward thermal management. Its robust construction ensures stable operation in demanding industrial environments.
